Model

MATX-6958

CPU

Support Intel 4th Core i3/i5/i7 LGA1150 CPU

Chipset

Intel H81

Graphic Control

CPU integration

Memory

2*UDIMM DDR3 Memory slot,DDR3 1333/1600MHz,The biggest can support 16GB

Storage

3*SATA,2*SATASupport SATA3.0,1*SATASupport SATA2.0

Display Port

1*VGA,1*DVI VGA up to 1920*1200 DVI up to 2560*1600

Ethernet

2*LAN Intel I211,10/100/1000Mbps RJ45

USB

2*USB3.0,14*USB2.0

Audio

1*Line-out,1*Mic-in,1*Line-in

COM

5*RS-232,1*RS-232/422/485

I/O

1*PCIe 16x Slots 1*PCIe 4x Slots 1*PCIe 1x Slots 1*PCI Slots 2*Mini-PCIe,1*Mini-PCIe support 3G/4G/Wifi,1*Mini-PCIe support MSATA 1* CPU FAN 1*SYS FAN 8*GPIO Support Input/Output programming

Watchdog

Support

BIOS

AMI UEFI BIOS

System

Windows 7,Windows 10,Linux

Power Supply

ATX

Temperature/humidity

Working temperature : 0℃～60℃ Storage temperature:-40℃～80℃ 5%～95% Relative humidity,No condensation

Size

244mm x 244mm
