Model

ATX-6953

CPU

Support Intel 4th Core i3/i5/i7 LGA1150 CPU

Chipset

Intel Q87/Z87

Graphic Control

CPU integration

Memory

4* Dual channel UDIMM Memory slot,Support DDR3 1333/1600MHz, Memory容量最高可达32GB

Storage

10*SATA 2.0

Display Port

1*VGA,1*DVI,1*HDMI VGA up to 1920x1200 DVI-D up to 1920x1200 HDMI up to 2560X1600

Ethernet

2*LAN  Intel 82574L,10/100/1000Mbps RJ45

USB

4*USB3.0,6*USB2.0

Audio

1*Line-out,1*Line-in,1*MIC-in,1*CD-in

COM

4*RS232,2*RS232/RS422/RS485

I/O

1*PCIe X16 and 1*PCIe X4,2*PCI,2,Mini-PCIe（One of the MiniPCIE Support 3G,another support SSD） Support PS/2 Mouse and keyboard Support 8*GPIO Support 1* CPUFAN（Support speed control),1*SYSFAN

Watchdog

Support

BIOS

AMI UEFI BIOS

System

Windows 7,Windows 10,Linux

Power Supply

ATX

Temperature/humidity

Working temperature:0℃～60℃ Storage temperature:-40℃～85℃ 5%～95% Relative humidity,No condensation

Size

305mm x 244mm
