Model

PPC-3311C

CPU

Intel Celeron J1900 (2M Cache,up to 2.42 GHz,Four nuclear)

Chipset

Intel Bay Trail

Graphic Control

up to 1366x768(1920x1080)

Memory

1*SO-DIMM slot,Support DDR3L-1066/1333MHz, The biggest can support 8GB

Storage

1*SATA,1*mSATA（Mini-PCIe interface）

Display Port

1*HDMI interface

Ethernet

4*LAN Intel I211, 10/100/1000Mbps RJ45

USB

1*USB3.0,5*USB2.0

Audio

Support 1*Mic_in,1*LINE_OUT,1*LINE_IN,1*5W Audio power amplifier interface

COM

2*RS232/RS422/RS485

I/O

Support 2*Mini-PCIe（One of the 1*Mini-PCIe can support 3G/4G/Wifi module（optional）,another 1*Mini-PCIe support mSATA) Support 8*GPIO Support 1*4PIN Fan interface Support 1*CONN extension Support PS/2 Mouse and keyboard

Watchdog

Support

BIOS

AMI UEFI BIOS

System

Windows,Linux

Power Supply

DC 12V (optional 9~36V)

Temperature/humidity

Working temperature : 0℃～60℃ Storage temperature:-40℃～80℃ 5%～95% Relative humidity,No condensation

Color

black

Mainboard model

BPC-7948

Cooling way

New fanless wide temperature heat dissipation structure

Installation

VESA（with stents 100mmx100mm）

Screen parameters

Screen Size 11.6" Aspect Ratio 16:9 Resolution 1366x768(1920x1080) Contrast Ratio 800:1 Brightness 300cd/m2 Maximum Color 16.7M

Touch screen

The whole plane Capacitive/resistive
