PPC-3317QC

Support Intel Celeron Processor J1900(2M Cache, up to 2.42 GHz),4*LAN,1*USB3.0,5*USB2.0,2*COM,17"

◆ Support Intel Celeron Processor J1900 (2M Cache, up to 2.42 GHz)

◆ 1*SO-DIMM DDR3L-1066/1333MHz

◆ 1*VGA,1*HDMI,1*LVDS

◆ 4*LAN,1*USB3.0,5*USB2.0,2*COM

◆ 2*Mini-PCIe

Ask Price Comparison
  • Product Specification
  • Download Center
  • Model

    PPC-3317C

    CPU

    Intel Celeron J1900 (2M Cache,up to 2.42 GHz,Four nuclear)

    Chipset

    Intel Bay Trail

    Graphic Control

    up to 1280x1024

    Memory

    1*SO-DIMM slot,Support DDR3L-1066/1333MHz, The biggest can support 8GB

    Storage

    1*SATA,1*mSATA(Mini-PCIe interface)

    Display Port

    1*HDMI interface

    Ethernet

    4*LAN Intel I211, 10/100/1000Mbps RJ45

    USB

    1*USB3.0,5*USB2.0

    Audio

    Support 1*Mic_in,1*LINE_OUT,1*LINE_IN,1*5W Audio power amplifier interface

    COM

    2*RS232/RS422/RS485

    I/O

    Support 2*Mini-PCIe(One of the 1*Mini-PCIe can support 3G/4G/Wifi module(optional),another 1*Mini-PCIe support mSATA) Support 8*GPIO Support 1*4PIN Fan interface Support 1*CONN extension Support PS/2 Mouse and keyboard

    Watchdog

    Support

    BIOS

    AMI UEFI BIOS

    System

    Windows,Linux

    Power Supply

    DC 12V (optional 9~36V)

    Temperature/humidity

    Working temperature : 0℃~60℃ Storage temperature:-40℃~80℃ 5%~95% Relative humidity,No condensation

    Size

    383.6mm x 216mm x 60mm

    Color

    black

    Mainboard model

    BPC-7948

    Installation

    Panel embedded

    Screen parameters

    Screen Size 17" Aspect Ratio 5:4 Resolution 1280x1024 Contrast Ratio 1000:1 Brightness 250cd/m2 Maximum Color 16.7M

    Touch screen

    The whole plane Capacitive/resistive
