Model

FW-1109

CPU

Intel Sandy/Ivy Bridge Core i3/i5/i7/Pentium/Celeron CPU

Chipset

Intel H61

Graphic Control

CPU integration

Memory

2*Dual channel DIMMSupport DDR3 1066/1333MHz,The biggest can support 16GB

Storage

1*3.5"HDD

Display Port

1*VGA(DB15)

Ethernet

Support 6个 GE,LAN3 and LAN4,LAN5 and LAN6 two network function with the third generation of Bypass

USB

3*USB2.0

Audio

COM

1* RJ-45 Console

I/O

Power indicator light,HDD light 3*System fan

Watchdog

Support

BIOS

AMI EFI BIOS

System

Power Supply

ATX 250W

Temperature/humidity

Working temperature : 0℃～60℃ Storage temperature:-40℃～80℃ 5%～95% Relative humidity,No condensation

Size

436mmx 350mmx 44.4mm

Color

black

Material

High quality carbon steel strength

Mainboard model

FWMB-7935

Cooling way

3*System fan

Installation

1U shelf mountable

Emc/safety
