Model

BIS-6330A

CPU

Support Intel Ivy Bridge Core i3/i5 CPU

Chipset

Intel HM76

Graphic Control

CPU integration

Memory

1*SO-DIMM,DDR3-1066/1333/1600MHz,The biggest can support 4GB

Storage

1*SATA3.0

Display Port

2*HDMI

Ethernet

1*LAN Realtek RTL8111E,10/100/1000Mbps,

USB

2*USB3.0

Audio

1*Mic-in,1* Line-out

COM

1*RS232

I/O

1*CPU FAN 8*GPIO

Watchdog

Support

BIOS

AMI UEFI BIOS

System

Windows 10,Linux

Power Supply

DC 12-19V

Temperature/humidity

Working temperature : 0℃～60℃ Storage temperature:-40℃～80℃ 5%～95% Relative humidity,No condensation

Size

200mm x 119mm x 30mm (W x D x H)

Color

black

Mainboard model

OPS-4922

Cooling way

initiative

Installation

Desktop/Wall
