Model

BIS-6660-F21

CPU

Support Intel 6/7th Core i3/i5/i7 BGA1356-U CPU

Graphic Control

CPU integration

Memory

2*SODIMM DDR4 slot,Support DDR4-1866/2133MHz,The biggest can support 32GB

Storage

2*SATA,1*MSATA

Display Port

1*HDMI,1*VGA,1*LVDS

Ethernet

4*LAN Intel I211,10/100/1000Mbps RJ45

USB

2*USB2.0,4*USB3.0

Audio

1*Mic-in,1*Line-out

COM

6*COM

I/O

2*CAN 2*MINI-PCIe 1*MXM extension slot 1*PS/2 32*GPIO

Watchdog

Support

BIOS

AMI UEFI BIOS

System

Windows 10,Linux

Power Supply

DC 9-36V

Temperature/humidity

Working temperature : 0℃～60℃ Storage temperature:-40℃～80℃ 5%～95% Relative humidity,No condensation

Size

280mm x 219.2mm x 62mm (W x D x H)

Color

silver

Mainboard model

BPC-7961+ACP-3201GP

Cooling way

passive

Installation

Desktop/Wall
