Model

MITX-6112

CPU

Support Loongson LS3A4000 CPU

Chipset

Loongson 7A1000

Graphic Control

Loongson 7A1000 integration

Memory

2*UDIMM slot,DDR4 2400Mhz,The biggest can support 32GB

Storage

2*SATA,Support SATA 2.0

Display Port

2*VGA VGA up to 1920*1080

Ethernet

2*LAN Intel I211/I210,10/100/1000Mbps RJ45

USB

4*USB3.0,11*USB2.0

Audio

1*Line-out,1*Mic-in,1*Line-in,1*AMP

COM

2*RS-232

I/O

1*PS2 1*PCIe 16x Slots,PCIe x8 signal 1*M.2 M KEY 2280,仅Support NVME agreement 2*Mini-PCIe,Support WIFI/3G/4G 1*SIM Card slot 1*JFP 1*LPC 4*PCIe x1 extended interface 1* CPU FAN 8*GPIO Support Input/Output programming

Watchdog

Support

System

Linux

Power Supply

ATX

Temperature/humidity

Working temperature:0℃～60℃ Storage temperature:-40℃～80℃ 5%～95% Relative humidity,No condensation

Size

170mm x 170mm
