Model

MATX-6551

CPU

Phytium FT-2000/4( Four Core ), D2000（ Eight Core ） CPU

Memory

2*UDIMM Memory slot，Support DDR4-3200MHz，The biggest can support 256GB

Storage

3*SATA,Support SATA 3.0 1*TF

Display Port

Support PCIe Discrete graphics display

Ethernet

2*LAN AR8035,10/100/1000Mbps RJ45

USB

18*USB2.0,4*USB3.0

Audio

1*Mic,1*Head Phone,1*Line IN

COM

13*RS232,3*RS485/232

I/O

1*PCIe x16 slot，2*PCIe x16 slot(PCIe 8X signal) 1*Mini-PCIe,Support MSATA 1*LPC 2*I2C 1* CPUFAN,1*SYSFAN

Watchdog

Support

BIOS

Byocore UEFI BIOS

System

UOS 20,Kylin V10

Power Supply

ATX

Temperature/humidity

Working temperature：0℃～60℃ Storage temperature：-40℃～85℃ 5%～95% Relative humidity,No condensation

Size

244mm x 244mm
