Model

EMB-7521

CPU

NXP LS1026A/1046A CPU

Memory

1*UDIMM DDR4 Memory slot，The biggest can support 8GB

Storage

1*SATA,Support SATA 3.0 1*eMMC,The biggest support 128GB

Ethernet

8*LAN,1*SFP+ 5*Qualcomm AR8033,10/100/1000Mbps RJ45 3*Intel i211,10/100/1000Mbps RJ45

USB

1*USB3.0,1*USB2.0

Audio

1*Headphone,2*MIC-IN,2*5W AMP

COM

1*RS-232,1*RS-485

I/O

1*Mini-PCIe(Support 4G module) 4*GPI,4*GPO 1*FAN

Watchdog

Support

System

Linux

Power Supply

DC 12V

Temperature/humidity

Working temperature：0℃～60℃ Storage temperature：-40℃～80℃ 5%～95% Relative humidity,No condensation

Size

210mm x 145mm
